C2202

C2202-ORIGINAL VIN MISMATCH/MISSING






When Monitored:

With the ignition on.

Set Condition:

When the Anti-Lock Brake Module fails the diagnostic test.

Possible Causes

- ANTI-LOCK BRAKE MODULE

1. ANTI-LOCK BRAKE MODULE CONFIGURATION

The Anti-lock Brake Module hardware check has determined that module configuration does not match vehicle con- figuration. Verify that the correct module part number is installed in the vehicle.
Turn the ignition on.
With the Scan Tool verify that the VIN stored in the controller matches the vehicle VIN.
With the Scan Tool, select Clear Stored DTCs.
Cycle the ignition off, then on.
With the Scan Tool, select View DTCs.

Does this DTC reset?

Yes

- Replace the Anti-lock Brake Module.
- Perform ABS VERIFICATION TEST - VER 1.

No

- Test complete.
- Perform ABS VERIFICATION TEST - VER 1.
