B1D53

B1D53-SWITCH POWER SUPPLY CIRCUIT LOW - DRIVER MEMORY MIRROR MODULE

For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

Continuously

- Set Condition:

If the Driver Memory Mirror Module detects an internal module failure.





Diagnostic Test

1. REPLACE THE DRIVER MEMORY MIRROR MODULE

Repair

- Replace the Driver Memory Mirror Module.
- Perform BODY VERIFICATION TEST - VER 1. Body Verification Test
