U1413

U1413-IMPLAUSIBLE ODOMETER SIGNAL RECEIVED





For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

Ignition on.

- Set Condition:

The odometer message the PCM is receiving is implausible. The circuit is continuously monitored. One Trip fault.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding.

Theory of Operation

The Front Control Module isn't receiving an odometer signal over CAN B from the Cluster Module. The FCM has to send the PCM an odometer signal over CAN C. The signal the FCM is sending over CAN C is implausible.

Diagnostic Test

1. ACTIVE DTC

Ignition on, engine not running.

With a scan tool, View DTCs.

Is the DTC Active at this time?

Yes

- Go To 2

No

- Refer to the INTERMITTENT CONDITION Diagnostic Procedure. Intermittent Condition

2. CAN B BUS HARDWARE DTCS ALSO ACTIVE

With a scan tool check for DTCs in the FCM.

Are any CAN B Hardware related DTCs Active at this time?

Yes

- Refer to Communications for the appropriate diagnostic procedures.

No

- Replace and program the Powertrain Control Module.
- Perform the POWERTRAIN VERIFICATION TEST. Powertrain Verification Test
