C1241

C1241-STEERING ANGLE SENSOR VELOCITY PERFORMANCE

For a complete wiring diagram Consult Diagrams/Electrical.

- When Monitored:
Continuously.

- Set Condition:
The Steering Column Module (SCM) has detected that the Steering Angle Sensor rotational speed has exceeded 3000 degrees per second.





Diagnostic Test

1. DTC IS ACTIVE
NOTE: If B210D-BATTERY VOLTAGE LOW or B210E-BATTERY VOLTAGE HIGH is set along with this DTC, diagnose the battery voltage DTC first.

Ignition on, engine not running.
Turn the steering wheel from stop to stop at least three times.
With the Scan Tool, select View DTCs in the Steering Column Module.
Is the DTC status Active at this time?

Yes

- Go to 2

No

- Go to 3

2. STEERING COLUMN MODULE (SCM)
View repair.


Repair

- Replace the Steering Column Module (SCM).

3. INTERMITTENT STEERING ANGLE SENSOR VELOCITY PERFORMANCE DTC
The conditions necessary to set this DTC are not present at this time.
Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
While monitoring the scan tool data relative to this circuit, wiggle test the wiring and connectors.
Look for the data to change or for the DTC to reset during the wiggle test.
Were any problems found?

Yes

- Repair as necessary.

No

- Test complete.
