Rear Bumper Attachment Bolt - Torque

7/4/95

76/05/95/US

SUBJECT
Rear Bumper Attachment Bolts

MODEL
Discovery

AFFECTED VEHICLES
LP
LH
LJ 126980 to 132088
LD

DETAIL

It as been noted that a small number of vehicles within the above Vin range, may have the rear bumper bolts below the specified torque. In some instances the rear fixing bolts may have a torque setting of 20 ft.lbs (27 Nm). The correct setting for these fixing bolts is 30-37 ft lbs (40-50 Nm).

ACTION REQUIRED

At the earliest opportunity check the rear bumper attachment bolts, and re-torque where necessary.

PARTS INFORMATION

Not applicable

PROCEDURE





Any vehicles within the above VIN range will require the rear bumper bolts to be checked, and re-torqued were necessary.

Rear bumper bolt torque setting 30-37 ft lbs (40- 50Nm).

WARRANTY

Normal warranty policy and procedures apply.

COMP. CODE

9R8G

SRO

76.22.89/28 - Check and re-torque rear bumper bolts - 0.15 hrs.
