Rear Washer Jet - New Design
01/09/9576/34/95/US
SUBJECT:
Shortened Rear Washer Jet - New Part Introduction
MODEL:
Discovery
AFFECTED VEHICLES
LP
LH All
LJ
LD
DETAIL
When a Discovery is put through an automatic car wash, the rear washer jet can sometimes be damaged.
A new shorter washer jet has been introduced to overcome this problem and is now available.
ACTION REQUIRED
Upon customer complaint of a broken washer replace with new part as detailed below.
PARTS INFORMATION
PRC6496 - New rear washer (supersedes PRC9008).
PROCEDURE
Refer to the workshop manual section 84 Rear Window Washer Jet.
Replace old type washer jet with new, shorter design.
Re-set both jets.
WARRANTY
Normal warranty policy and procedure apply
COMP. CODE
6Q1D
SRO
84.30.09 - Rear washer jet renew - 00.25 hr.
