Parking Brake Warning Switch: Service and Repair

Switch - Handbrake Warning

Service Repair No - 70.35.40

Removal
1. Remove center console.





2. Remove screw securing switch.
3. Release lead from switch.
4. Remove switch.

Installation
1. Connect lead and position switch to handbrake lever, ensuring lug on handbrake lever locates in hole in switch. Fit and tighten screw.
2. Fit center console.
