Removal and Replacement

Front Seat
This is a "Trustmark Authoring Standards (TAS) Repair Procedure"
- TAS style procedures can be identified by steps that have no accompanying step text and the magenta color of the electrical connectors and fasteners such as nuts, bolts, clamps or clips.
- TAS removal and installation procedures use a sequence of color illustrations to indicate the order to be followed when removing/disassembling or installing/assembling a component.
- Many of the TAS procedures will have the installation information within the removal steps.
- The TAS color illustrations use a variety of symbols to indicate important details of the procedures. It is important to understand these symbols in order to properly used the TAS procedures.
Refer to How to Use TAS Procedures and TAS Symbol Glossary at Vehicle | Description and Operation for additional information on these TAS procedures.
For additional information, refer to How to Use TAS Procedures How to Use TAS Procedures

Removal

NOTE:
Removal steps in this procedure may contain installation details.
1 Disconnect the battery ground cable.
For additional information, refer to Specifications [1][2]Battery

WARNING: To avoid accidental deployment, the restraints control module backup power supply must be depleted. Wait at least two minutes after disconnecting the battery ground cable(s) before commencing any repair or adjustment to the supplemental restraint system (SRS), or any component(s) adjacent to the SRS sensors. Failure to follow these instructions may result in personal injury.
2 Make the SRS system safe.
For additional information, refer to Standard Workshop Practices Standard Workshop Practices

CAUTION: Make sure that new bolts are installed.

Torque to: 40 Nm

CAUTION: Protect the surrounding paintwork to avoid damage.

CAUTION: Care must be taken to avoid damaging the surrounding components.
3 Remove the seat through the door aperture.

NOTE:
Do not disassemble further if the component is removed for access only.

Torque to: 4.5 Nm

Installation
1 To install, reverse the removal procedure.
