Windshield Washer Spray Nozzle: Testing and Inspection

INSPECTION







1. CHECK WINDSHIELD WASHER NOZZLE
a. While operating the washer, check if the point where the washer fluid hits the windshield is within the range indicated by the hatched line.







2. CHECK REAR WASHER NOZZLE
While operating the washer, check if the point where the washer fluid hits the back door glass is within the range indicated in the illustration.
