[A26MX-R]



Service Specifications

Clutch:





Flywheel Installation

Caution: Clean the crankshaft threads before tightening the bolts. The threads may be damaged if the bolts are tightened with any old sealant remaining.

Gradually tighten the flywheel lock bolts in a crisscross pattern.

Tightening torque 151.3 - 161.1 N-m, (15.3 - 16.4 kgf-m, 111.6 - 118.8 ft-lbf)

Clutch Cover Installation






Tighten the bolts evenly and gradually in a crisscross pattern.

Tightening torque 25 - 33 N-m (2.6 - 3.3 kgf-m, 19 - 24 ft-lbf)
