Pneumatic System, Accessories
Preparation for Test
1. Review All-Activity-Module (N10) diagnostics.
2. All fuses OK.
3. Voltage supply to All-Activity- Module (N10) is OK,
4. Connect the Hand-Held Tester (HHT) to X11 /4, according to diagram, see section 0.
4. HHT serial interface is OK.
Special Tools:
Test equipment; See MBNA Standard Service Equipment Program
Description Brand, model, etc.
Digital multimeter Fluke models 23, 77 III, 83,85,87
