GF88.79-P-2005GH Retrieve Stored Exterior Mirror Position, Function

GF88.79-P-2005GH Retrieve Stored Exterior Mirror Position, Function
- as of 1.9.01 with CODE (275b) Memory package (driver's seat, mirrors)

Component Identification:

Function requirements
- No overvoltage/undervoltage
- Term.15R or 15 ON
- Both potentiometers of adjustment motor supply plausible values
- No manual adjustment currently in progress
- No blocking detected

Function, example (LHS):
The stored positions of the
- left electrically adjustable and heated exterior mirror (M21/1)
- right electrically adjustable and heated exterior mirror (M21/2)

can be retrieved using the left front seat adjustment switch group with memory (S91).

This is done by pressing and holding the
- memory position 1 switch (S91s6) or
- memory position 2 switch (S91s7) or
- memory position 3 switch (S91s8)
at the left front seat adjustment switch group with memory (S91) until the stored position is set.

The left front seat adjustment control module with memory (N32/1) actuates the exterior mirror position through the lower control panel control module (N72).

The motors in the exterior mirrors continue to be operated by the seat control module until the set position is detected by the position measurement.

If one of the switches, memory position 1(S91s6), memory position 2 (S91s7), memory position 3 (S91s8), is released, this stops the mirror moving into the stored position.

It is also possible to retrieve stored seat positions using the memory function.
