GF88.79-P-3004GH Store Exterior Mirror Park Position, Function

GF88.79-P-3004GH Store Exterior Mirror Park Position, Function
- as of 1.9.01 with CODE (275b) Memory package (driver's seat, mirrors)

Function requirements
- No overvoltage/undervoltage
- Term.15R or 15 ON
- Vehicle speed v = 0 km/h
- Exterior mirror left or right adjustment selector (N72/8) in passenger-side mirror position

Function, example (LHS):
The desired park position of the exterior mirror on the passenger side must be set manually using the exterior mirror adjustment switch (N72s7).
The park position is stored using the left front seat adjustment switch group with memory (S91), and is stored in the left front seat adjustment control module with memory (N32/1).

The park position is stored by pressing the memory switch (S91s9) for t ≥ 40 ms in the left front seat adjustment switch group with memory (S91) and then pressing the "mirror down" exterior mirror adjustment switch (N72s7) within t ≤ 3 s.

Depending on the selection, the park position is assigned
- to memory position 1 switch (S91/6) or
- memory position 2 switch (S91/7) or
- memory position 3 switch (S91/8);
a park position is stored in any of these mirror positions.
If the passenger-side mirror is already in a park position, this is altered and stored.

The exterior mirror and seat positions can also be stored using the memory buttons 1, 2, 3.
