AR86.30-S-2071JC Remove/Install Fresh Water Tank Shutoff Lever

AR86.30-S-2071JC Remove/Install Fresh Water Tank Shutoff Lever

- with CODE (ZO1) Camper James Cook Compact
- with CODE (ZO2) Camper James Cook Classic







1 Shock absorber
3 Cover
4 Hose
5 Shutoff cock
6 Fitting










906 589 07 63 00, Assembly aid
