A.Evaporator Manufacturer I.D. Model 123 With AC and/or ACC

FIGURE 1 - BEHR A/C:

FIGURE 2 - SIEMENS/THERMAL A/C:

FIGURE 3 - BEHR ACC:

FIGURE 4 - SIEMENS/THERMAL ACC:

Evaporators made by two manufacturers (Behr and Siemens/Thermal) are used in the manual air conditioning and automatic climate control systems. These evaporators are not interchangeable in terms of spare parts replacement. The evaporator manufacturer can be visually identified by removing the glove compartment to insure that the proper evaporator is ordered/installed (Figures 1-4).

FIGURE 1 - BEHR A/C:

Evaporator for A/C system made by Behr:

Lever of main air flap without part number. Additional part number label attached as of 8/80.

FIGURE 2 - SIEMENS/THERMAL A/C:

Evaporator for A/C system made by Siemens/Thermal:

Lever of main air flap has part number (arrow).

FIGURE 3 - BEHR ACC:

Evaporator for ACC system made by Behr:

Part number label attached and main air flap lever (arrow) is white.

FIGURE 4 - SIEMENS/THERMAL ACC:

Evaporator for ACC system made by Siemens/Thermal:

Main air flap lever (arrow) is black.
