A/T - (722.4) Updated Lower Cover & Intermediate Plate

86MERCEDES02
TO: OUR MERCEDES-BENZ PASSENGER CAR DEALERS

DATE: October 1986 REF.NO. 27/74


SUBJECT: LOWER COVER, INTERMEDIATE PLATE AND GASKET TRANSMISSION 722.4


As of April 1985 production, the lower cover, large intermediate plate, and gasket have been modified and installed on transmission 722.4.

Effective Serial Number


Model Transmission End Number


722.4 206489

FIGURE 1 - MODIFIED LOWER COVER:

The modified lower cover can be installed in earlier 722.4 transmissions only together with the large intermediate plate and new gasket. The new intermediate plate and new gasket may not be used in conjunction with the previous version lower cover. For further information, see Service Microfiche Automatic Trans mission 722.4, job no.. 27-004.
NOTE: The front cover gasket can be used repeatedly, as long as it is not damaged. Do not apply sealant to the sealing surface. If sealant enters oil ducts, it will cause shifting problems and also damage the transmission.


Parts Information


Part Name Part Number


Lower cover 123 270 19 05
Intermediate plate 123 277 33 14
Gasket 123 277 04 80


Time Allowance

Please refer to the latest time guide microfiche, grp. 27.
