Ignition - Dual Ignition Adapter for Bear Analyzer

REF.NO.: MBNA 58/57

DATE: October 1992

TO: OUR MERCEDES-BENZ PASSENGER CAR DEALERS

SUBJECT:
BEAR DUAL IGNITION DIAGNOSTIC ADAPTOR FOR BEAR D.A.C.E. ENGINE ANALYZER








The Sear diagnostic adaptor 43-322 for dual ignition systems (Figure 1) is now available. The adaptor is designed to replace the diagnostic and secondary lead cables on the 40-960 D.A.C.E. engine analyzer. Currently, the adaptor is only suitable for 8 cylinder engines, since the version which includes the 12 cylinder engine is still undergoing final testing. The initial 8 cylinder version of the adaptor will be upgraded to include the 12 cylinder engine by inserting a circuit board in the adaptor. When available, this upgrade will be performed by a local Bear representative at no charge.
