GF32.30-P-2400P Nivomat Damping, Function

GF32.30-P-2400P Nivomat Damping, Function
- MODEL 203.2 (except 203.242 /243 /246) as of 13.1.03
- with CODE (480) Level control system at rear
- MODEL 203.242 /243 /246
- with CODE (480) Level control system at rear





10 Nivomat damping element, driver-side
11 Nivomat damping element, passenger side
13 Dividing piston
14 Oil intake tube
15 Damping piston
16 Oil reservoir
17 Pump rod
19 Pressure control valve
20 Pump chamber
21 Suction valve
22 Rebound buffer
26 High pressure reservoir
28 Bypass
30 Drain hole
31 Piston rod

The Nivomat damping element, driver-side (10) and the Nivomat damping element, passenger side (11) feature 2 different types of damping.

These are:
^ Speed-dependent basic damping
^ Load-sensitive additional damping

The damping function is carried out by openings that are covered by flexible valve plates.

Basic damping
As the damping piston (15) moves in the damping fluid, the fluid flows through the piston valves and the resulting flow energy is converted into heat.

Load-sensitive additional damping
Load-sensitive additional damping is generated by the pump of the Nivomat damping element, driver-side (10) and the Nivomat damping element, passenger side (11). The additional damping acts in the rebound direction and increases as the load increases.
