GF82.61-P-4000RM Destination Guidance In Digitalized MAP Area, Function

GF82.61-P-4000RM Destination Guidance In Digitalized Map Area, Function
- Model 230.474/475
- with CODE (527) COMAND APS (with navigation)

On journeys within the digitized map area the following information calculated by the navigation processor (N41/1) is available to the user:
^ The current route and position of the vehicle on a digital map
^ Route list
^ Distance from the destination and estimated time of arrival
^ Direction recommendation
^ Arrow indicating the driving direction
^ Name of the road currently being traveled along
^ Name of the road to turn into
^ Distance from the next junction (specified in units of length or as a bar graph)

For destination guidance, 3 illustration modes are possible:
^ with map
^ with map and symbol display before turn-off points
^ with symbol display (route control symbols)

The scale of the map can be changed in stages (50 m/cm to 500 km/cm on the screen). Moreover, it is possible to select whether the map is aligned in the direction of travel (forward) or facing North (to the North).

Blaupunkt Travelpilot DX navigation digital versatile disk (DVD)
Separate one-way lanes (fine geometry) are automatically displayed with this DVD.

The DVD type (with the latest fine geometry) is automatically detected and the graphic displayed in a 2nd optimized set of line thickness.The voice output supplements the actual navigation.
