Door Switch
>>
Description and Operation
Door Switch: Description and Operation
GF82.20-P-4102T Door Contact Switch, Location/Task/Design/Function
Component Identification:
In Model 211.6, depending on equipment and special body, the number and position of the interior lamps may vary.
