GF80.20-P-3004TX Unlocking By Opening A Door, Function

GF80.20-P-3004TX Unlocking By Opening A Door, Function

Unlock
The vehicle doors can always be opened from the inside regardless of the status of the central locking (CL)The corresponding door lock is then unlocked mechanically.

Special case
A globally unlocked vehicle is locked with the interior central locking and ATA function display switch (N72/1s6) in the upper control panel control module (N72/1) or the automatic locking/ relocking function.
In this case, the vehicle is unlocked globally when the driver or passenger door is opened from inside.
Control is performed in the EIS control module (N73).
The status of the driver and passenger door is transmitted by the rear SAM control module with fuse and relay module (N10/2) via the controller area network bus class B (interior compartment) (CAN-B).
