GF68.05-P-0001RC Garage Door Opener, Function
GF68.05-P-0001RC Garage Door Opener, Function
- with CODE (231) Garage door opener
- with CODE (232) Garage door opener with frequency 284-390 MHz
Function requirements, general
^ C. 15R On
^ Garage door opener system functioning properly
Garage door opener, general
The garage door opener transmitter unit is a remote control capable of learning with which various receivers of the opening and locking systems for doors or gates can be activated.
The garage door opener is installed in the housing of the overhead control panel control unit (N70).
The garage door opener radio signal has a range of approx. s = 15 m.
The garage door opener function comprises the following partial functions:
^ Function sequence, transmit radio signal
^ Function sequence, program the memories
^ Function sequence, erase the memories
^ Function sequence for resetting to as-delivered state
Function sequence, transmit radio signal
If one of the following buttons is actuated, the garage door opener transmitter unit (A26/10) transmits the radio signal assigned to this memory location:
- Garage door opener button 1 (A26/10s1)
- Button 2 garage door opener (A26/10s2)
- Button 3 garage door opener (A26/10s3)
Function feedback is accomplished via the Garage door opener indicator lamp (A26/10e1).
Priority for simultaneous actuation
Highest priority: Button 1
Middle priority: Button 2
Lower priority: Button 3
Function sequence, programming the memories
Keep the required button pressed for a time of at least t = 20 s. As a result the system changes into learning mode which is displayed by the flashing of the garage door opener with f = 1 Hz. Continue to press selected button and hold original hand transmitter close to the garage opener transmitter unit with transmitter function activated for up to t = 90 s (s = 3 to 20 cm). The transmission frequency is now learnt.
In the process the garage door opener transmitter unit searches for the suitable frequency among the possible transmission frequencies. If the learning process is completed, this is confirmed by rapid flashing of the garage door opener indicator lamp with f = 5.6 Hz.
If the learn-in procedure is not completed after t = 90 s, the garage door opener transmitter unit is deactivated.
If the original hand transmitter is not compatible with the garage door opener, a universal receiver ("Fix Kit Receiver") which reacts to the in-plant programming of the garage door opener can be installed in the garage.
Function sequence, erase the memories
To erase the memories, press the two outer buttons (buttons 1 and 3) simultaneously for a period of a least t = 20 s. The garage door opener indicator lamp flashes for a period of t = 10 s. Release the buttons again during the flashing phase. The existing data of the memory locations is erased.
The next time one of the three buttons is actuated, the garage door opener transmitter unit changes to the learning mode.
If no programming is performed in learning mode during a period of t = 100 s, the garage door opener transmitter unit switches off automatically to protect the on-board electrical system.
Function sequence for resetting to as-delivered state
To reset press the two outer buttons (buttons 1 and 3) simultaneously for at least t = 30 s.
Settings:
with code (232) Garage door opener at frequency of 284-390 MHz:
- "Chamberlain" algorithm
with code (231) Garage door opener:
- "KEELOQ" algorithm
