Operation CHARM
: Car repair manuals for everyone.
Home
>>
Mercury
>>
1990
>>
Topaz AWD L4-140 2.3L HSC (VIN X)
>>
Repair and Diagnosis
>>
Power and Ground Distribution
>>
Locations
>>
Ground Locations
Ground Locations
Ground 708 Black Wire:
GROUND No. 708
