Evaporator Core: Service and Repair

REFRIGERANT LINES


Removal and Installation for Evaporator







REMOVAL
1. Remove the expansion valve. Refer to Service and Repair.
2. Remove the instrument lower cover RH. Refer to Component Parts.
3. Remove the glove box. Refer to Removal And Installation.





4. Remove the evaporator cover (1).
5. Remove the evaporator (2).

INSTALLATION
Installation is in the reverse order of removal.

CAUTION:
- Replace the O-rings with new ones, then apply compressor oil to them when installing them.
