Windshield Washer Spray Nozzle: Adjustments

FRONT WASHER


FRONT WASHER NOZZLE : Adjustment
















- To adjust the front washer nozzles (1), insert a suitable tool (A) into the nozzle hole (B) and move it up or down and left or right to adjust the spray into the specified spray zone.
