Oldsmobile
>>
1987
>>
Firenza V6-173 2.8L
>>
Repair and Diagnosis
>>
Powertrain Management
>>
Diagrams
>>
Electrical Diagrams
>>
A/C Compressor, Air Flow Sensor & Emission Control
A/C Compressor, Air Flow Sensor & Emission Control
Fig. 234 Multi-Port Fuel Injection Wiring Circuit (Air Flow Sensor, A/C Compressor & Emission Control W/V6-173/2.8L Engine:
