Automatic Transmission/Transaxle

The vertical axis represents line pressure PSI. Line #1 represents Reverse gear Line #2 represents Park, Neutral, and Drive gear Cooler Flow Rates: 1500 + RPM = 7 - 9 liters per minute at Min Line, 12 - 14 litre per minute at Max Line.
