Lighting and Horns: Service and Repair

Interior Lamp Control Switches

Interior Lamp Control Switches:

REMOVE OR DISCONNECT
1. Negative battery cable.
2. Disable SIR system.
3. Snap interior lamp control assembly from trim plate with a blunt tool.
4. Electrical connector.

INSTALL OR CONNECT
1. Electrical connectors
2. Switch into cluster trim plate.
3. Enable SIR system.
4. Negative battery cable.
