Center Mounted Brake Lamp: Service and Repair

REMOVAL PROCEDURE
1. Remove the rear seat.
2. Remove the rear seat to window trim panel.
3. Remove the bolts (2) that retain the stoplamp to the trim panel.
4. Remove the electrical connector (3).
5. Remove the center high mounted stoplamp (1).

INSTALLATION PROCEDURE
1. Install the electrical connector (3) to the center high mounted stoplamp (1).
2. Install the stoplamp to the trim panel by sliding the lamp assembly rearward against the rear window.

NOTE: Refer to Fastener Notice in Cautions and Notices.

3. Install the bolts (2) in order to retain the stoplamp to the trim panel.

Tighten
Tighten the bolts (2) to 5 N.m (44 lb in). Tighten the bolts in the sequence shown in the illustration.

4. Install the rear seat to rear window trim panel.
5. Install the rear seat.
