Condenser Fan: Testing and Inspection

Fan Motor Terminal ID:

1. Disconnect fan motor electrical connector.
2. Ensure fan motor operates when battery voltage is applied to terminal 3 and terminal 4 is grounded.
3. If motor does not operate as described, replace motor.
