System Diagram
Engine Controls Schematics
DLC, Ground, MIL and Power
Engine Controls Diagram 1:
5-Volt and Low References
Engine Controls Diagram 2:
MAF, VSS and Extended Brake Travel Switch
Engine Controls Diagram 3:
Heated Oxygen Sensors
Engine Controls Diagram 4:
Electronic Throttle Controls
Engine Controls Diagram 5:
Ignition System
Engine Controls Diagram 6:
Bank 1 Ignition Coils
Engine Controls Diagram 7:
Bank 2 Ignition Coils
Engine Controls Diagram 8:
Camshaft Position (CMP) Sensors and Solenoids
Engine Controls Diagram 9:
Fuel Injectors and Fuel Pump
Engine Controls Diagram 10:
EVAP Controls and FTP Sensor
Engine Controls Diagram 11:
Controlled/Monitored Subsystem References
Engine Controls Diagram 12:
