Garage Door Opener Transmitter: Description and Operation

Integrated Garage Door Opener

The integrated garage door opener provides the option of a single unit installed in the Cayenne's passenger compartment which can replace up to three radio remote control units operating, for example, a door opener, a gate opener or an alarm system. The integrated garage door opener "learns" the radio frequencies of all common remote control units and can then transmit these frequencies itself.

The control and transmitter unit of the garage door opener is integrated into the roof console. Programming and operating is by using the buttons.

Both fixed and variable codes can be learned and programmed in a short time.







Technical Data:
- 3-channel transceiver
- 27/30/40/418/433 MHz
- AM/FM Modulation
- Standard and variable code compatible
- Integration with vehicle network
- Power supply using the vehicle battery Reprogrammable at any time

Programming and synchronization procedures are described in detail in the owner's manual, chapter "Garage Door Opener".

Additional information can be obtained on the Internet at www.homelink.com
HomeLink is a registered trademark of Johnson Controls.
