B0078

B0078

B0078 Passenger Side Airbag Sensor, Open Circuit Or Short To Ground/B+.







Fault symptoms
Airbag warning lamp on.

Conditions
Ignition ON

Fault criteria
The control module has detected a fault in communication with the side impact sensor.

System reaction to a fault
The control module ignores all signals from the impact sensor as long as the fault is present.

Diagnostic help







[Fault Diagnosis Procedure]
