SPORT Indicator, Information Display

SPORT Indicator, Information Display








On cars equipped with automatic transmission the indicator lights up when the SPORT button on the gear selector lever is depressed. The sport function can be selected when the gear selector lever is in either the D or N position.


In the SPORT mode, the transmission remains longer in each gear. The TCM continuously sends the bus information: SPORT, unit ON/OFF.


The indicator on the information display is switched off under the following conditions:



^ When the sport button is depressed again.


^ When the transmission is in Limphome mode.


^ When Winter mode is selected.


^ If the ignition is turned off and then on again.


^ The selector lever is moved to P or R.



Diagnosis


The function has no diagnostics.
