Evaporator Drain Tube: Service and Repair
EVAPORATOR CONDENSATE DRAIN TUBEREMOVAL
1. Remove evaporator condensate drain tube screw and remove drain tube.
INSTALLATION
1. In stall evaporator condensate drain tube and bolt.
Torque:
Condensate Drain Tube Bolt: 3.5 N.m (31 in-lbs)
