With on-Board Refueling Vapor Recovery

DTC P1440 - FUEL TANK PRESSURE CONTROL SYSTEM FUNCTION PROBLEM (LOW INPUT)

DTC DETECTING CONDITION:
- Two consecutive driving cycles with fault

CAUTION: After repair or replacement of faulty parts, conduct CLEAR MEMORY and INSPECTION MODES. Clearing Diagnostic Trouble Codes





WIRING DIAGRAM
