Rear Wiper and Washer
Rear Wiper and Washer
Adjustments
1.
Adjust
wiper blade
in original position as shown in figure by changing
wiper arm
installation.
2.
Adjust washer ejecting point on rear gate window as shown in the figure when the vehicle stops.
