DTC 28

DTC 28 REAR LEFT ABNORMAL ABS WHEEL SPEED SENSOR SIGNAL

DIAGNOSIS:
- Faulty ABS wheel speed sensor signal (noise, irregular signal, etc.)
- Faulty harness/connector

TROUBLE SYMPTOM:
ABS does not operate.

















WIRING DIAGRAM
