Operation CHARM
: Car repair manuals for everyone.
Home
>>
Subaru
>>
2010
>>
Impreza F4-2.5L SOHC
>>
Repair and Diagnosis
>>
Specifications
>>
Capacity Specifications
>>
Heating and Air Conditioning
>>
System Specifications
System Specifications
General Description
SPECIFICATION
1.
HEATER SYSTEM
2.
A/C SYSTEM
-
Auto A/C model
-
Manual A/C model
