C0076

DTC C0076 CLUTCH SIGNAL

DTC DETECTING CONDITION:
Abnormal clutch signal

TROUBLE SYMPTOM:
Hill start assist does not operate.

NOTE:
Depending on the user clutch operation patterns, the hill start assist warning light may illuminate for a while, and then go off.

Illumination condition:
While the condition such vehicle speed 10 km/h or more, clutch switch signal ON (depressed) lasts for 5 minutes or more, if the vehicle speed drops below 10 km/h or less, the module judges this condition as abnormal (clutch switch stuck ON), then illuminates the warning light.
Turning off condition:
If the clutch switch signal OFF (foot released) condition continues for 1 second, the module turns off the warning light.
The hill start assist function does not operate, while the warning light illuminates.

WIRING DIAGRAM:
