A/T And M/T - Transmission Numbers Location/Description

REFERENCE TRANSMISSION
AND CLUTCH
NUMBER 018
DATE 4-27-84
MODEL ALL

Manual Transmission:




MANUAL TRANSMISSION:




2.Automatic Transmission:




The purpose of this service bulletin is to provide information regarding the location of and how to read them.. This bulletin contains information for both Automatic and Manual transmissions.

1. Manual Transmission

Model Code


Code Model Code Model

A A40 J A43


B A40D K A42DL


C A42D L A43DE


D A41 M A42DE


E - - N A44D


F A43D P A44DL


G A60 Q A44DE


H A43DL
