Supra L6-183 2997cc 3.0L DOHC Turbo (2JZ-GTE)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Antenna
Antenna
Auto Antenna Wiring Diagram:
Auto Antenna Wiring Diagram:
