Headlamp Wiper Motor: Testing and Inspection








INSPECT HEADLIGHT CLEANER MOTOR OPERATION
Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, check that the motor operates.


NOTE: These tests must be performed quickly (within 20 seconds) to prevent the coil from burning out. If operation is not as specified, replace the motor.
