Compressor Speed Sensor: Testing and Inspection

MEASURE SENSOR RESISTANCE
1. Disconnect the connector.
2. Measure resistance between terminals 3 and 6.

Standard resistance:
240 ± 80 Ohms at 20 °C (68 °F)

If resistance is not as specified, replace the sensor.
