Clock: Service and Repair

REPLACEMENT

1. REMOVE CONSOLE PANEL UPPER
2. REMOVE HEATER CONTROL KNOB
3. REMOVE INSTRUMENT CLUSTER FINISH PANEL




4. REMOVE CLOCK ASSY
a. Using a screwdriver, disengage the 4 claws, remove the clock as shown in the illustration

HINT: Tape the screwdriver tip before use
