Luggage Room Light Circuit

LUGGAGE ROOM LIGHT CIRCUIT

CIRCUIT DESCRIPTION
The body ECU receives luggage compartment door information, and turns on the luggage compartment light.

Wiring Diagram:

Step 1-2:

Step 3-4:

INSPECTION PROCEDURE
