Driver and Passenger Airbag System - OBD

Group: 01

Number: 96-01

Date: Jan. 5, 1996

Subject:
Driver and Passenger Airbag System On Board Diagnostic (OBD)

Model(s):
Golf/GTI/Jetta 1995

Production

This Technical Bulletin describes the airbag system with expanded On Board Diagnostic capabilities that has been installed starting with 09.94 production.










J��A:


























The Repair Manual pages are new and will be integrated with the next Repair Manual update.
