Engine - Crankshaft, Cylinder Block Revisions

Group: 13

Number: 95-01

Date: Oct. 16, 1995

Subject:
Engine - Crankshaft, Cylinder Block
2.0 Liter Engine Code ABA

Model(s):
Golf III/Jetta III/Cabrio 1996 -->

File this Technical Bulletin in Repair Manual No: W42 011 294 105

This information describes changes in engine components and specifications for the 2.0 liter engine starting with August, 1995 production (OBD II).

















This information is formatted for the Repair Manual and will be integrated during the next update.
