General (VDO Instrument Panel)

Turbo:

Naturally Aspirated:

The VDO combined instrument panel has a built-in microprocessor with diagnostic functions, which continuously monitors itself and its input and output signals. The diagnostic function can be used to read off diagnostic trouble codes (DTCs), read input and output signals, test the instrument gauges, read control module identification and reset the service reminder indicator (SRI).

When replacing the combined instrument panel it must be programmed for market, mileage, service interval. For further information see Diagnostics, Reading/Programming Combined instrument panel.

The simplest way of identifying the VDO combined instrument panel is by the instrument display. Application and ID
