Refrigerant Drainage, Filling and Recycling Units
RHS 1000 Refrigerant Drainage And Recycling Unit
- This unit is designed for use on cars with R12 refrigerant in the A/C system, and can be used to collect and purify refrigerant from the car.
In the unit, the refrigerant is "washed" and stored in a glass storage cylinder prior for return to the charging unit or to a storage bottle.
- Part Number (981 2401-9).
RHS 3000 Refrigerant Drainage And Recycling Unit
- This unit is designed for use on cars with R12 refrigerant in the A/C system, and can be used to collect, purify and recycle refrigerant, and to vacuum-pump/test and recharge the A/C system in the car.
- RHS 3000 replaces the DS 450 and RHS 1000 units.
- Part Number (981 2402-7).
RHS 850 Refrigerant Drainage And Recycling Unit
- This unit has been developed especially for Volvo cars.
- The unit may be used only on cars with R134a in the A/C system. Only R134a may be used in systems for which it has been specified. R134a is an environmentally sound refrigerant containing only fluorine, compared with R12, which is a CFC hydrocarbon.
- A label in the engine compartment and a yellow tag on the service valve indicate that the system is filled with R134a.
- The RHS 850 can be used to drain, purify and recycle refrigerant. In addition, it can be used to vacuum-pump, test and recharge the A/C system in the car.
- Part Number (9511000-3)
RHS 650 Refrigerant Drainage And Recycling Unit
- This unit has been developed especially for R134a.
- The unit is used to drain, purify and recycle refrigerant. In addition, it can be used to vacuum-pump, test and charge the A/C system in the car.
- The different settings on the unit enable it to be used on all cars with R134a in the A/C system. Only R134a may be used in systems for which it has been specified (see plate in engine compartment). R134a must not be mixed with other refrigerants or used in A/C systems for which other refrigerants are specified, otherwise compressor failure may result.
- Part Number (951 2310-5)
